Features
:
* All Chinese blue screen interface and the perfect combination of intelligent operating system, so that more user-friendly instrument
.
* Functional, 18 kinds of input, output, synchronous operation, independent operation, power supply isolation, independently of each other.
* A V, mV, mA, ¦¸, and thermocouple (TC), thermal resistance (RTD) signal output and measurement .24 VDC loop power distribution providing power for the transmitter output, and can simultaneously measure the output of the transmitter mA Value.
* With frequency (Hz) of the measurement and simulation capabilities
.
* All-digital operation, intelligent menu; more intuitive and simpler, so users handy
.
* Direct Type Thermocouple (Thermal Resistance) ¡æ value, display and output the corresponding mV (¦¸) values, without having to search indexing table
.
* Thermocouple measurement (thermal resistance) signals, ¡æ, mV, ¦¸ also showed
.
* High-precision temperature sensor provides cold junction compensation for thermocouple
.
* All signals can be in any fine-tuning on the median or continuous change
.
* Analog transmitter function, can check DCS channel 4 ~ 20mA loop current
.
* Optional according to need any number of high-precision digital pressure modules, in order to achieve accurate measurement of pressure, the pressure module selection in Table V.
With RS232 communication interface, through the PC to achieve rapid correction instrument tolerance
.
* AC-DC dual-use, built-in high performance imports of high-capacity rechargeable lithium battery, a charge can work for 8 hours or more, depending on the instrument changes in working conditions
.
* Imported chassis, beautiful and practical
.
* Dimensions: 250mm * 200mm * 85mm Weight 1Kg
|
